Key Features
- Triple Function LED RCL — Integrated Rear Position (RPL), Stop, and Direction Indicator (DI) functions
- High-Intensity 27 LED Array — Optimized 13.5W output for clear, wide-angle signaling visibility
- Multi-Voltage Compatibility — 8V to 30V range, perfect for both 12V and 24V commercial systems
- Premium Acrylic (PMMA) Lens — Superior light transmission with high resistance to UV and impact
- Reinforced ABS Base — Lightweight yet highly durable body designed for heavy-duty environments
- Precision PC Metalized Reflector — Enhances LED light distribution for maximum road safety
- Energy-Efficient Technology — Significantly longer service life with reduced power consumption
- Universal Commercial Fitment — Engineered specifically for buses, coaches, and heavy trailers
Specifications LED RCL 8V–30V PMMA/ABS
Product Group
Rear Combination Lamps (LED RCL)
Lamp Composition
Rear Position (RPL), STOP, and Direction Indicator (DI) Functions
Light Source
High-Performance 27 LED Configuration
Operating Voltage
8V – 30V DC (Multi-Voltage Compatible)
Total LED Power
13.5W Multi-Function Output
Lens Material
High-Grade Acrylic (PMMA)
Base Material
Impact-Resistant ABS (Acrylonitrile Butadiene Styrene)
Reflector System
PC Metalized Precision Optics
Application
Commercial Buses, Heavy-Duty Coaches, and Trailers
Specification Document — HL-912 RCL
Download detailed product specifications (PDF, 1.5 MB)
